Local AI Agentic Coding: Model Selection, VRAM Guide, LM Studio Setup

Step-by-Step Breakdown

1. Find your VRAM or unified memory

   Windows: Open Task Manager (Ctrl+Shift+Esc) → Performance tab → GPU. Look for "Dedicated GPU Memory" — this is your VRAM figure.
   Mac (M-series): Apple menu → About This Mac → Memory. The number shown is unified memory, shared between CPU and GPU. Intel Macs have very limited integrated GPU VRAM and are not practical for this workflow.

2. Calculate usable capacity

   Windows: Subtract ~10% for overhead — usable ≈ 90% of your VRAM figure.
   Mac M-series: Subtract 20–25% for OS and other processes — usable ≈ 75–80% of unified memory. A 64 GB Mac effectively has ~50–52 GB available for a model.

3. Match model size to your hardware

   Use the table below to pick the largest model your hardware can run at full speed. Going over VRAM causes the model to spill into system RAM — generation becomes very slow.

4. Download LM Studio (free)

   LM Studio is a free desktop app that runs AI models locally and exposes a local API server. Download it from lmstudio.ai, install, and open it. No account required.

5. Download two models inside LM Studio

   Search for models in LM Studio's model browser. Download two: (1) Qwen 2.5 Coder 1.5B as your autocomplete model — this runs on virtually any hardware and is fast enough for keystroke-level completion; (2) the largest Qwen family model that fits your usable VRAM for chat, editing, and agentic tasks. LM Studio shows a warning if a model likely exceeds your hardware before you download.

6. Start the local server

   In LM Studio, go to the Local Server tab. Toggle the server on (one click). Load your chat/agent model onto the server. The server now listens at http://localhost:1234 with an OpenAI-compatible API.

7. Configure your coding tool to use the local endpoint

   In Kilo Code, Cursor, or another agentic coding tool, open the model provider settings and add a custom OpenAI-compatible provider pointing to http://localhost:1234/v1. Select your loaded model as the active model. Your coding agent now runs entirely on your machine.

VRAM → Model Size Cheat Sheet

Quantized versions (Q4_K_M is a good balance; Q8 is higher quality at double the size) let you fit slightly larger models. LM Studio recommends the right quantization for your hardware.

Commands & Paths

http://localhost:1234/v1

http://localhost:1234/v1

Purpose: LM Studio's default local server endpoint — OpenAI-compatible API.

When to use: Paste this as the "base URL" in any coding tool that accepts a custom OpenAI-compatible provider (Kilo Code, Cursor, Continue.dev, etc.).

Find VRAM on Windows via Task Manager

Ctrl+Shift+Esc → Performance → GPU → Dedicated GPU Memory

Purpose: Identifies how much VRAM your dedicated graphics card has.

When to use: Before selecting a model — this number determines the maximum model size you can run at full speed.

Find unified memory on Mac

Apple menu → About This Mac → Memory

Purpose: Shows total unified memory on M-series Macs, which is shared between CPU and GPU.

When to use: M1/M2/M3/M4/M5 Macs only — this figure (minus ~20–25%) is your effective model size ceiling.

Common Errors & Fixes

Mac vs Windows: Speed vs Capacity

Mac M-series has a key advantage and a key limitation compared to a dedicated Windows GPU:

• Mac advantage — capacity: unified memory means all your RAM is available to the GPU. A 64 GB M5 Max can run a 70B model; a 24 GB RTX 4090 maxes out at ~32B.
• Windows advantage — speed: dedicated GPU memory bandwidth on an RTX 4090 is ~1,008 GB/s vs ~546 GB/s on an M4 Max. Windows dedicated GPUs generate tokens significantly faster at equivalent model sizes.

Choose Mac if you want larger models and don't mind slightly slower generation. Choose a high-end Windows GPU if you want maximum tokens-per-second on a mid-size model.

Gotchas & Caveats

• Two models, not one: autocomplete and chat/agent are different use cases with different latency requirements. A 1.5B model is fast enough for keystroke autocomplete; a 7B+ model is needed for coherent multi-step agentic tasks.
• Quantization matters: Q4_K_M is the standard balance of size and quality. Q2 models are significantly degraded; Q8 is near-full quality at ~2× the size. LM Studio surfaces quantization options automatically.
• Not all "local AI" content is agentic coding: running a local chat model and running a local agentic coding workflow are different. Agentic coding requires the model to execute bash commands, write files, and iterate — confirm your coding tool supports tool use with local models before investing setup time.
• The Qwen family leads for coding tasks — but the landscape changes fast. Check community benchmarks on Hugging Face's Open LLM Leaderboard before downloading if it has been more than a few months since this video.

Key Takeaways

• VRAM (Windows) or unified memory (Mac M-series) is the single number that determines which model sizes you can run locally at usable speed.
• You need two models: a tiny fast one (~1.5B) for autocomplete, and a larger capable one for chat, editing, and agentic tasks.
• LM Studio handles model discovery, hardware-fit warnings, quantization, and the local API server — it's the easiest way to get started.
• The Qwen family is currently the best-performing open model family for local agentic coding across hardware tiers.
• Local agentic coding is fully offline — useful for travel, privacy-sensitive work, and eliminating per-token costs entirely.
